Duration (Minutes)When current flows through wire, heat is generated because of the resistance that the current encounters in the wire. As current flows through a wire, the temperature of the wire increases until heat flows out to the surroundings at the same rate that is generated. Large wires are slower to heat up to their final value. Therefore, it helps to know how long current will flow in a circuit before current stops flowing and heat is no longer generated.
Calculator Size Software Wireless
When the duration of current flow is long, larger wire may be recommended under certain circumstances.
Copper Wire Size Chart
/ / Voltage Drop CalculatorThis is a calculator for the estimation of the voltage drop of an electrical circuit based on the wire size, distance, and anticipated load current. Please note this calculator assume the circuit is operate in a normal condition—room temperature with normal frequency.
The actual voltage drop can vary depend on the condition of the wire, the conduit being used, the temperature, the connector, the frequency etc. It is recommended that the voltage drop should be less than 5% under the fully loaded condition. Please use one-way distance to the load.
